characteristic
1. It adopts imported Yaskawa frequency converter and customized PLC program controller, which can add all required functions according to user's setting.
2. The touch screen and button are used to control the acceleration, parking and automatic of the machine, which can be controlled freely at a glance.
3. The machine PLC accurately controls the pneumatic valve to ensure that the temperature accuracy is within 1 ℃.
4. The machine has the functions of automatic temperature control, automatic track counting, automatic turning, automatic parking and manipulation.
5. The machine adopts pneumatic control to open and close the door, and a sealing strip is installed beside the door.
6. The dyeing process can be set according to the user's requirements, and can be centrally controlled by multiple jigging machines at the same time to ensure the dyeing quality.
7. Users can add automatic feeding system, cloth discharging device, etc. according to requirements.
8. According to the user's requirements, we can build machines with all stainless steel housings such as frames to increase the service life of the machine
特点：
1、采用进口安川变频器，定制PLC程序控制器，可根据用户要设定增加所需的所有功能。
2、采用触摸屏及按钮双路控制机器加速、停车、自动等控制自如，一目了然。
3、机器PLC精确控制气动阀门，保证温度控制精度在1℃之内。
4、机器自动控温，自动计道、自动调头、自动停车及摆布功能。
5、机器采用气动控制开、关门，且在门边加装密封条。
6、可根据用户要求设置染色工序，并同时可以多台卷染机集中控制，以保证染色质量。
7、用户可根据要求增加自动加料系统、出布装置等。
8、可根据用户要求制作机架等外壳全部用不锈钢的机器。增加机器使用寿命，一步到位。
主要技术参数Main technical parameter：
织物最大卷布直径 Max.diameter of cloth roll φ680-1600mm
织物门幅 Max. working fabric width 1600-3600mm
卷布辊直径 Diameter of main roller φ220-φ400mm
织物线速度 Adjustable fabric rate 10-150m/min
织物张力 Tension of fabrics 3-60kg
装机容量 Installed capacity 3-18kw
重量 Weight 2-5t
|
